GGD AC low voltage fixed switchgear
GGD low-voltage power distribution cabinet is suitable for power distribution systems with AC 50Hz, rated working voltage 380V and rated working current up to 3150A of power users such as power plants, substations, factories and mines, etc., as power conversion, distribution and control of power, lighting and power distribution equipment.
GGD type low-voltage distribution cabinet is based on the Department of Energy in charge of the superior and the majority of power users and design department requirements, in line with the principle of safety, economy, reasonable and reliable design of new low-voltage distribution cabinet. The product has the characteristics of high breaking capacity, good dynamic and thermal stability, flexible electrical scheme, convenient combination, series, strong practicability, novel structure and high protection level. It can be used as the replacement product of low-voltage switchgear.
The shipping cost of the order is borne by the buyer
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
描述
Conditions of use：
The ambient air temperature of α shall not be higher than 40 ℃, not lower than-5C, and the average temperature within 24 hours shall not be higher than 35 ℃; For indoor installation and use, the altitude of the use place shall not exceed 2000m;
Α The relative humidity of the surrounding air shall not exceed 50% at the highest temperature of +40 ℃, and a larger relative humidity shall be allowed at a lower temperature (for example, 90% at +20 ℃), taking into account the influence of accidental condensation due to temperature changes;
Α When the equipment is installed, the inclination from the vertical plane shall not exceed 5 °;
Alpha equipment should be installed in the place without severe vibration and impact, and not enough to make electrical components subject to corrosion; users have special requirements can be negotiated with the manufacturer to solve.
Additional information
| color | Blue, Red, Yellow |
|---|
